Multimeter Guide for School Science Projects

Table of Content

• A Multimeter and how it works

• Anatomy of a Multimeter

• Measuring Voltage

• Measuring resistance
• Measuring Current
• Multimeters in a typical school science project
• Conclusion
• Frequently Asked Questions

In a science or electronics class, there are few more useful tools for a student to master than a multimeter. In any electrical circuit, there are three quantities that must be considered: voltage, electrical current, and resistance. Whatever kind of experiment the student may be performing (building a basic circuit to light up an LED with a battery, or testing what is conductive and what is not), a multimeter will give the kind of direct, interpretable results that every experiment relies on. Schools that put their students to work with a multimeter very early on give those students a real advantage because the process of using one in the lab directly bridges the gap between the abstract and the measurable.

In the first place, the device can seem a bit intimidating to a new electronics student at the lab or to someone doing a STEM education project for the first time. It has a variety of switches, a rotary dial with a lot of markings, and two or three separate input terminals. The operation itself is not nearly as complicated as it appears once the different settings have been clearly explained to the student. By explaining the operation to the student in an easy-to-understand format, the use of a multimeter will be a great asset in any science project. This article walks the student through all the features of the multimeter.

A Multimeter and how it works

A multimeter combines several measuring abilities in one handheld instrument. The word "multi-meter" can be broken down into these two words,multi - multiple, meter-measurement. In the older laboratories, separate pieces of equipment dealt with Voltage, current, and resistance. These were called the voltmeter, ammeter, and ohmmeter, respectively. The modern multimeter includes all three in one convenient and portable instrument. This makes it far more user-friendly and practical for student use.

There are two types of multimeters:

●     Analog multimeters are those that use a printed scale with a moving needle to show the measurement taken. While rare in schools, they can be quite useful for showing what's happening in a circuit over a period of time.

●     Digital multimeters are the other type and show the measurement as a digital readout. For use in a science lab kit in schools, it is the digital multimeter which must be used as it is the easiest to read, and least susceptible to human error.

Internally, the incoming current will pass through several resistors and other electronic components, converting it into a value that can be displayed. The actual precision of the reading is often down to the quality of the instrument itself, and the more likely reason for a discrepancy will be the user's failure to switch the instrument to the correct reading setting.

Anatomy of a Multimeter

Prior to taking the first measurement, it is important to familiarize oneself with how the meter feels and looks. One common cause for incorrect readings, or possible damage to the multimeter is the failure to follow this step.

The main components are:

●     The Display: This is what actually tells you the figure you get after taking a measurement. Most multimeters have an appropriate unit, for example: V for Volts, A for Amperes, or some daft-looking symbol for Ohms.

●     The Dial: In the center of the meter, there is a dial, which allows you to select what you would like to measure, as well as the range. Each point of selection is clearly labeled, even if sometimes they are hard to understand.

●     The input ports: Generally, the multimeter will have 3 input ports, labeled COM or a negative sign for the black wire, and the port for volts and small amps, and a separate 10 or 20 amp port.

●     The probes: the two leads that connect to the meter, usually red and black. The black wire always connects to COM.

Getting in the habit of checking where to plug the leads in before taking any measurement is a habit that many electricians maintain throughout their entire careers.

Measuring Voltage

This is likely the most used function of your student projects. What this tells the student is the amount of electrical potential between two points of a circuit.

Measuring D.C. Voltage (on battery-powered circuits):

●     Connect the black lead to the COM port and the red lead to the VmA port.

●     Select the rotary switch for the area for D.C. Voltage. This will usually be marked with a V and either a straight line or two straight lines.

●     Select a voltage range that is greater than the amount that you expect. If working with a 9-volt battery, then use the 20V range if the setting is there with most electrical testing tools.

●     Touch the red wire to the positive voltage source, and touch the black wire to the negative voltage source.

●     Look at the value that the display shows. If it shows a value around 9 volts, your battery is working, and your circuit is functioning.

Here are a couple of useful things to note about measuring voltage:

●     If the meter reads "1" followed by nothing, then your voltage is higher than the selected range. Increase the range that is selected.

●     For a.c. Voltage (which would normally only be present in teacher demonstrations, which are running on the mains power), change the dial to the a.c. Voltage setting. This is usually represented by a V and a wavy line. Schools that include this as part of a science lab kit for students give learners a fuller picture of how the instrument works across both circuit types.

●     You should always set the range higher and move down from that to a smaller value. This saves the meter from the wrong readings and potential damage.

Measuring resistance

Resistance measurement is particularly useful in science lab kits for students because it allows direct testing of whether a component is functioning, what value a resistor actually has, and whether a wire is conducting properly. Unlike current measurement, resistance testing requires no power source and works on isolated components alone.

To measure resistance:

 Ensure that the component being tested is disconnected from a power supply. A live circuit, when measured, will give the incorrect value, and it can damage the multimeter.

●      Attach the black probe to COM and the red probe to the VmA port.

●      Set the multimeter to the resistance section, which can be found using the Greek symbol for ohms.

●      Touch both probe ends to the wire or component being tested.

●      Take the reading from the screen, which should give a value in ohms, kilohms or megaohms depending on what is selected.

Practical uses in science lab projects:

●      See if a resistor's colour-coded value is correct

●      See if a wire has any worthwhile resistance

●      See if a switch is conducting electricity (reading close to 0 ohms when switched on)

 to test a faulty component that will be displayed as OL (overload) or 1 (indicating open circuit)

Measuring Current

The way you measure current requires a different connection from how you would measure voltage and resistance. This is where students make the most common errors. The multimeter needs to be in series with the circuit. The current that you want to measure needs to flow through the multimeter.

Steps to measuring small DC current:

1. Switch off the power to the circuit before making connections.

2. Connect the black probe to COM, the red probe to the mA input for small currents (under 200mA) or to the 10A input for large currents.

3. Break the circuit at the place you wish to measure. The multimeter sits between the two points in the broken circuit.

4. Turn the dial to DC current and select an appropriate range (must be higher than the value expected).

5. Switch on the power to the circuit and read the current value.

Crucial Warnings for Students:

●     Never connect the meter in parallel to measure current; doing this will effectively short out the circuit. If the meter is connected in parallel, it will blow an internal fuse, or a more severe permanent fault may occur. This is one of the most critical safety rules when working with electronics lab tools.

●     Ensure you use the correct port. The 10A port on most instruments is different and separated from the standard input port.

●     Remember to return the red lead to the normal input port after you are finished measuring current, before you use it to measure voltages.

Multimeters in a typical school science project

In actual student experiments, a multimeter proves to be very useful. Here are a few typical school projects that would benefit.

●     Testing a circuit's continuity: While making up a circuit on a breadboard, a continuity test is used to ensure that connections have been made correctly. A buzzer sounds on a multimeter, and close to 0 ohms is registered when two connected points are tested. Finding a broken/loose wire can be done this way efficiently.

●     Testing batteries: The average battery might be rated at 1.5V, but may be anywhere between 1.55V when at full charge. Once it runs down, this might be at 1.2V or less. Test batteries to check if it is simply a case of a lack of power.

●     Checking components: Colour codes on resistors can be erased or difficult to see. An ohmmeter gives a reading in seconds, whereas squinting at things with no light to see them is a waste of time.

Testing the conductivity of materials: Often, the science experiment that is done is to find out which materials conduct electricity. Place the probes on opposite sides of a material, and you get a non-readable, infinity, or a readable low resistance value. If the reading is not infinite, electricity has passed across the material without the need for unnecessary light. This makes it one of the most straightforward applications of STEM education tools in a classroom setting.

Conclusion

In conclusion, the multimeter is an indispensable piece of equipment to have in any student's electrical toolbox, not only in the science lab where electrical circuits are a key component, but also in a student's own study of science and construction of their own projects at home. Being able to operate such equipment (which is what using a multimeter entails) by choosing the correct range and reading values of a circuit gives the student a transferable skill that will continue into the later stages of education and even into professional life. The interpretation of values, once they have been taken, also makes concepts become less of an abstract idea and something that can be observed. When outfitting a science laboratory kit or providing tools for an educational endeavor (STEM), a good-quality digital multimeter should be considered a high priority.

Frequently Asked Questions

1. What kind of multimeter is best suited to science projects at school?

A simple digital multimeter, which is capable of measuring DC voltage, resistance and DC current with a continuity test will be adequate for school science projects. A multimeter made by a reputable electrical testing firm that features a continuity buzzer and is auto-ranging will be useful for students, as it minimises errors associated with selecting the appropriate range.

2. Is it possible for a student to damage a multimeter?

Yes, a few mistakes can cause permanent damage. The most frequent error is plugging the probes into the wrong ports when attempting to measure current, which does not go through the device protection and burns out the fuse. Reading voltage whilst the dial is set to resistance mode is a common mistake. By following the steps within this document, both can be avoided.

3. What is OL on a digital multimeter?

OL denotes overload, which can happen either if the measurement you are trying to take exceeds the scale setting you have it on or if there is no complete path for electricity to flow through when testing resistance or continuity. If it is the former, then all you need to do is set it to a higher range. For resistance testing, OL usually signifies an open circuit or a broken component.

4.Is a multimeter a type of voltmeter?

A voltmeter can only measure voltage, whereas a multimeter measures voltage along with several other quantities. As such, multimeters are now most commonly found used in classrooms or professional contexts as opposed to voltmeters that are for voltage measurement only, as they fulfil multiple roles in a single device.

5. At what age, or year level, should students first use a multimeter?

Students generally first start using multimeters during their secondary education, from approximately 12 to 14 years old when electrical science becomes part of their syllabus at school. Students at an earlier age within a structured STEM education programme could also use multimeters with supervision, and while low voltage, battery powered projects, will not provide a risk at these early ages.
